Alpha Vantage APIs are grouped into three categories: (1) Time Series Data, (2) Technical Indicators, and (3) Sector Performances. All APIs are realtime: the latest data points are derived from the current trading day. Examples in this documentation are for demo purposes. Claim your free API key today to explore our full API offerings!

Time Series Data Realtime

Time Series Data provides realtime and historical equity data in 4 different temporal resolutions: (1) intraday, (2) daily, (3) weekly, and (4) monthly. Daily, weekly, and monthly time series contain up to 20 years of historical data. Intraday time series typically span the past 10 to 15 active trading days.


TIME_SERIES_INTRADAY High Usage


This API returns intraday time series (timestamp, open, high, low, close, volume) of the equity specified, updated realtime.


API Parameters

❚ Required: function

The time series of your choice. In this case, function=TIME_SERIES_INTRADAY

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min

❚ Optional: outputsize

By default, outputsize=compact. Strings compact and full are accepted with the following specifications: compact returns only the latest 100 data points in the intraday time series; full returns the full-length intraday time series. The "compact" option is recommended if you would like to reduce the data size of each API call.

❚ Optional: datatype

By default, datatype=json. Strings json and csv are accepted with the following specifications: json returns the intraday time series in JSON format; csv returns the time series as a CSV (comma separated value) file.

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=TIME_SERIES_INTRADAY&symbol=MSFT&interval=1min&apikey=demo

https://www.alphavantage.co/query?function=TIME_SERIES_INTRADAY&symbol=MSFT&interval=15min&outputsize=full&apikey=demo

Downloadable CSV file:

https://www.alphavantage.co/query?function=TIME_SERIES_INTRADAY&symbol=MSFT&interval=1min&apikey=demo&datatype=csv


TIME_SERIES_DAILY High Usage


This API returns daily time series (date, daily open, daily high, daily low, daily close, daily volume) of the equity specified, covering up to 20 years of historical data.

The most recent data point is the cumulative prices and volume information of the current trading day, updated realtime.


API Parameters

❚ Required: function

The time series of your choice. In this case, function=TIME_SERIES_DAILY

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Optional: outputsize

By default, outputsize=compact. Strings compact and full are accepted with the following specifications: compact returns only the latest 100 data points; full returns the full-length time series of up to 20 years of historical data. The "compact" option is recommended if you would like to reduce the data size of each API call.

❚ Optional: datatype

By default, datatype=json. Strings json and csv are accepted with the following specifications: json returns the daily time series in JSON format; csv returns the time series as a CSV (comma separated value) file.

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=TIME_SERIES_DAILY&symbol=MSFT&apikey=demo

https://www.alphavantage.co/query?function=TIME_SERIES_DAILY&symbol=MSFT&outputsize=full&apikey=demo

Downloadable CSV file:

https://www.alphavantage.co/query?function=TIME_SERIES_DAILY&symbol=MSFT&apikey=demo&datatype=csv


TIME_SERIES_DAILY_ADJUSTED High Usage


This API returns daily time series (date, daily open, daily high, daily low, daily close, daily split/dividend-adjusted close, daily volume, dividend amount, split coefficient) of the equity specified, covering up to 20 years of historical data.

The most recent data point is the cumulative prices and volume information of the current trading day, updated realtime.


API Parameters

❚ Required: function

The time series of your choice. In this case, function=TIME_SERIES_DAILY_ADJUSTED

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Optional: outputsize

By default, outputsize=compact. Strings compact and full are accepted with the following specifications: compact returns only the latest 100 data points; full returns the full-length time series of up to 20 years of historical data. The "compact" option is recommended if you would like to reduce the data size of each API call.

❚ Optional: datatype

By default, datatype=json. Strings json and csv are accepted with the following specifications: json returns the daily time series in JSON format; csv returns the time series as a CSV (comma separated value) file.

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=TIME_SERIES_DAILY_ADJUSTED&symbol=MSFT&apikey=demo

https://www.alphavantage.co/query?function=TIME_SERIES_DAILY_ADJUSTED&symbol=MSFT&outputsize=full&apikey=demo

Downloadable CSV file:

https://www.alphavantage.co/query?function=TIME_SERIES_DAILY_ADJUSTED&symbol=MSFT&apikey=demo&datatype=csv


TIME_SERIES_WEEKLY


This API returns weekly time series (last trading day of each week, weekly open, weekly high, weekly low, weekly close, weekly volume) of the equity specified, covering up to 20 years of historical data.

The latest data point is the cumulative prices and volume information for the week (or partial week) that contains the current trading day, updated realtime.


API Parameters

❚ Required: function

The time series of your choice. In this case, function=TIME_SERIES_WEEKLY

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Optional: datatype

By default, datatype=json. Strings json and csv are accepted with the following specifications: json returns the weekly time series in JSON format; csv returns the time series as a CSV (comma separated value) file.

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=TIME_SERIES_WEEKLY&symbol=MSFT&apikey=demo

Downloadable CSV file:

https://www.alphavantage.co/query?function=TIME_SERIES_WEEKLY&symbol=MSFT&apikey=demo&datatype=csv


TIME_SERIES_MONTHLY


This API returns monthly time series (last trading day of each month, monthly open, monthly high, monthly low, monthly close, monthly volume) of the equity specified, covering up to 20 years of historical data.

The latest data point is the cumulative prices and volume information for the month (or partial month) that contains the current trading day, updated realtime.


API Parameters

❚ Required: function

The time series of your choice. In this case, function=TIME_SERIES_MONTHLY

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Optional: datatype

By default, datatype=json. Strings json and csv are accepted with the following specifications: json returns the monthly time series in JSON format; csv returns the time series as a CSV (comma separated value) file.

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=TIME_SERIES_MONTHLY&symbol=MSFT&apikey=demo

Downloadable CSV file:

https://www.alphavantage.co/query?function=TIME_SERIES_MONTHLY&symbol=MSFT&apikey=demo&datatype=csv


Technical Indicators Realtime

Technical indicator values are updated realtime: the latest data point is derived from the current trading day of a given equity.


SMA High Usage


This API returns the simple moving average (SMA) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=SMA

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each moving average value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=SMA&symbol=MSFT&interval=15min&time_period=10&series_type=close&apikey=demo

https://www.alphavantage.co/query?function=SMA&symbol=MSFT&interval=weekly&time_period=10&series_type=open&apikey=demo


EMA High Usage


This API returns the exponential moving average (EMA) values. See also: mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=EMA

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each moving average value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=EMA&symbol=MSFT&interval=15min&time_period=10&series_type=close&apikey=demo

https://www.alphavantage.co/query?function=EMA&symbol=MSFT&interval=weekly&time_period=10&series_type=open&apikey=demo


WMA


This API returns the weighted moving average (WMA) values. See also: mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=WMA

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each moving average value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=WMA&symbol=MSFT&interval=15min&time_period=10&series_type=close&apikey=demo

https://www.alphavantage.co/query?function=WMA&symbol=MSFT&interval=weekly&time_period=10&series_type=open&apikey=demo


DEMA


This API returns the double exponential moving average (DEMA) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=DEMA

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each moving average value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=DEMA&symbol=MSFT&interval=15min&time_period=10&series_type=close&apikey=demo

https://www.alphavantage.co/query?function=DEMA&symbol=MSFT&interval=weekly&time_period=10&series_type=open&apikey=demo


TEMA


This API returns the triple exponential moving average (TEMA) values. See also: mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=TEMA

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each moving average value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=TEMA&symbol=MSFT&interval=15min&time_period=10&series_type=close&apikey=demo

https://www.alphavantage.co/query?function=TEMA&symbol=MSFT&interval=weekly&time_period=10&series_type=open&apikey=demo


TRIMA


This API returns the triangular moving average (TRIMA) values. See also: mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=TRIMA

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each moving average value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=TRIMA&symbol=MSFT&interval=15min&time_period=10&series_type=close&apikey=demo

https://www.alphavantage.co/query?function=TRIMA&symbol=MSFT&interval=weekly&time_period=10&series_type=open&apikey=demo


KAMA


This API returns the Kaufman adaptive moving average (KAMA) values.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=KAMA

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each moving average value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=KAMA&symbol=MSFT&interval=15min&time_period=10&series_type=close&apikey=demo

https://www.alphavantage.co/query?function=KAMA&symbol=MSFT&interval=weekly&time_period=10&series_type=open&apikey=demo


MAMA


This API returns the MESA adaptive moving average (MAMA) values.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=MAMA

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Optional: fastlimit

Positive floats are accepted. By default, fastlimit=0.01.

❚ Optional: slowlimit

Positive floats are accepted. By default, slowlimit=0.01.

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=MAMA&symbol=MSFT&interval=15min&series_type=close&fastlimit=0.02&apikey=demo


T3


This API returns the triple exponential moving average (T3) values. See also: mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=T3

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each moving average value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=T3&symbol=MSFT&interval=15min&time_period=10&series_type=close&apikey=demo

https://www.alphavantage.co/query?function=T3&symbol=MSFT&interval=weekly&time_period=10&series_type=open&apikey=demo


MACD High Usage


This API returns the moving average convergence / divergence (MACD) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=MACD

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Optional: fastperiod

Positive integers are accepted. By default, fastperiod=12.

❚ Optional: slowperiod

Positive integers are accepted. By default, slowperiod=26.

❚ Optional: signalperiod

Positive integers are accepted. By default, signalperiod=9.

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=MACD&symbol=MSFT&interval=15min&series_type=close&fastperiod=10&apikey=demo

https://www.alphavantage.co/query?function=MACD&symbol=MSFT&interval=daily&series_type=open&apikey=demo


MACDEXT


This API returns the moving average convergence / divergence values with controllable moving average type. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=MACDEXT

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Optional: fastperiod

Positive integers are accepted. By default, fastperiod=12.

❚ Optional: slowperiod

Positive integers are accepted. By default, slowperiod=26.

❚ Optional: signalperiod

Positive integers are accepted. By default, signalperiod=9.

❚ Optional: fastmatype

Moving average type for the faster moving average. By default, fastmatype=0. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

❚ Optional: slowmatype

Moving average type for the slower moving average. By default, slowmatype=0. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

❚ Optional: signalmatype

Moving average type for the signal moving average. By default, signalmatype=0. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=MACDEXT&symbol=MSFT&interval=15min&series_type=close&fastmatype=1&apikey=demo

https://www.alphavantage.co/query?function=MACDEXT&symbol=MSFT&interval=daily&series_type=open&apikey=demo


STOCH High Usage


This API returns the stochastic oscillator (STOCH) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=STOCH

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Optional: fastkperiod

The time period of the fastk moving average. Positive integers are accepted. By default, fastkperiod=5.

❚ Optional: slowkperiod

The time period of the slowk moving average. Positive integers are accepted. By default, slowkperiod=3.

❚ Optional: slowdperiod

The time period of the slowd moving average. Positive integers are accepted. By default, slowdperiod=3.

❚ Optional: slowkmatype

Moving average type for the slowk moving average. By default, slowkmatype=0. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

❚ Optional: slowdmatype

Moving average type for the slowd moving average. By default, slowdmatype=0. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=STOCH&symbol=MSFT&interval=15min&slowkmatype=1&slowdmatype=1&apikey=demo

https://www.alphavantage.co/query?function=STOCH&symbol=MSFT&interval=daily&apikey=demo


STOCHF


This API returns the stochastic fast (STOCHF) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=STOCHF

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Optional: fastkperiod

The time period of the fastk moving average. Positive integers are accepted. By default, fastkperiod=5.

❚ Optional: fastdperiod

The time period of the fastd moving average. Positive integers are accepted. By default, fastdperiod=3.

❚ Optional: fastdmatype

Moving average type for the fastd moving average. By default, fastdmatype=0. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=STOCHF&symbol=MSFT&interval=15min&fastkperiod=6&fastdmatype=1&apikey=demo

https://www.alphavantage.co/query?function=STOCHF&symbol=MSFT&interval=daily&apikey=demo


RSI High Usage


This API returns the relative strength index (RSI) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=RSI

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each RSI value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=RSI&symbol=MSFT&interval=15min&time_period=10&series_type=close&apikey=demo

https://www.alphavantage.co/query?function=RSI&symbol=MSFT&interval=weekly&time_period=10&series_type=open&apikey=demo


STOCHRSI


This API returns the stochastic relative strength index (STOCHRSI) values. See also: mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=STOCHRSI

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each STOCHRSI value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Optional: fastkperiod

The time period of the fastk moving average. Positive integers are accepted. By default, fastkperiod=5.

❚ Optional: fastdperiod

The time period of the fastd moving average. Positive integers are accepted. By default, fastdperiod=3.

❚ Optional: fastdmatype

Moving average type for the fastd moving average. By default, fastdmatype=0. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=STOCHRSI&symbol=MSFT&interval=15min&time_period=10&series_type=close&fastkperiod=6&fastdmatype=1&apikey=demo


WILLR


This API returns the Williams' %R (WILLR) values. See also: mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=WILLR

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each WILLR value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=WILLR&symbol=MSFT&interval=15min&time_period=10&apikey=demo


ADX High Usage


This API returns the average directional movement index (ADX) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=ADX

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each ADX value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=ADX&symbol=MSFT&interval=15min&time_period=10&apikey=demo


ADXR


This API returns the average directional movement index rating (ADXR) values. See also: mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=ADXR

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each ADXR value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=ADXR&symbol=MSFT&interval=15min&time_period=10&apikey=demo


APO


This API returns the absolute price oscillator (APO) values. See also: mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=APO

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Optional: fastperiod

Positive integers are accepted. By default, fastperiod=12.

❚ Optional: slowperiod

Positive integers are accepted. By default, slowperiod=26.

❚ Optional: matype

Moving average type. By default, matype=0. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=APO&symbol=MSFT&interval=15min&series_type=close&fastperiod=10&matype=1&apikey=demo


PPO


This API returns the percentage price oscillator (PPO) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=PPO

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Optional: fastperiod

Positive integers are accepted. By default, fastperiod=12.

❚ Optional: slowperiod

Positive integers are accepted. By default, slowperiod=26.

❚ Optional: matype

Moving average type. By default, matype=0. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=PPO&symbol=MSFT&interval=15min&series_type=close&fastperiod=10&matype=1&apikey=demo


MOM


This API returns the momentum (MOM) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=MOM

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each MOM value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=MOM&symbol=MSFT&interval=15min&time_period=10&series_type=close&apikey=demo


BOP


This API returns the balance of power (BOP) values.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=BOP

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=BOP&symbol=MSFT&interval=15min&apikey=demo


CCI High Usage


This API returns the commodity channel index (CCI) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=CCI

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each CCI value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=CCI&symbol=MSFT&interval=daily&time_period=10&apikey=demo


CMO


This API returns the Chande momentum oscillator (CMO) values. See also: mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=CMO

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each CMO value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=CMO&symbol=MSFT&interval=weekly&time_period=10&series_type=close&apikey=demo


ROC


This API returns the rate of change (ROC) values. See also: Investopedia article.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=ROC

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each ROC value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=ROC&symbol=MSFT&interval=weekly&time_period=10&series_type=close&apikey=demo


ROCR


This API returns the rate of change ratio (ROCR) values. See also: Investopedia article.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=ROCR

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each ROCR value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=ROCR&symbol=MSFT&interval=daily&time_period=10&series_type=close&apikey=demo


AROON High Usage


This API returns the Aroon (AROON) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=AROON

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each AROON value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=AROON&symbol=MSFT&interval=daily&time_period=14&apikey=demo


AROONOSC


This API returns the Aroon oscillator (AROONOSC) values. See also: mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=AROONOSC

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each AROONOSC value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=AROONOSC&symbol=MSFT&interval=30min&time_period=10&apikey=demo


MFI


This API returns the money flow index (MFI) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=MFI

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each MFI value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=MFI&symbol=MSFT&interval=weekly&time_period=10&apikey=demo


TRIX


This API returns the 1-day rate of change of a triple smooth exponential moving average (TRIX) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=TRIX

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each TRIX value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=TRIX&symbol=MSFT&interval=daily&time_period=10&series_type=close&apikey=demo


ULTOSC


This API returns the ultimate oscillator (ULTOSC) values. See also: mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=ULTOSC

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Optional: timeperiod1

The first time period for the indicator. Positive integers are accepted. By default, timeperiod1=7.

❚ Optional: timeperiod2

The second time period for the indicator. Positive integers are accepted. By default, timeperiod2=14.

❚ Optional: timeperiod3

The third time period for the indicator. Positive integers are accepted. By default, timeperiod3=28.

❚ Required: apikey

Your API key. Claim your free API key here.


Examples (click for JSON output)

https://www.alphavantage.co/query?function=ULTOSC&symbol=MSFT&interval=30min&timeperiod1=8&apikey=demo

https://www.alphavantage.co/query?function=ULTOSC&symbol=MSFT&interval=daily&apikey=demo


DX


This API returns the directional movement index (DX) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=DX

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each DX value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=DX&symbol=MSFT&interval=30min&time_period=10&apikey=demo


MINUS_DI


This API returns the minus directional indicator (MINUS_DI) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=MINUS_DI

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each MINUS_DI value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=MINUS_DI&symbol=MSFT&interval=weekly&time_period=10&apikey=demo


PLUS_DI


This API returns the plus directional indicator (PLUS_DI) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=PLUS_DI

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each PLUS_DI value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=PLUS_DI&symbol=MSFT&interval=30min&time_period=10&apikey=demo


MINUS_DM


This API returns the minus directional movement (MINUS_DM) values. See also: Investopedia article


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=MINUS_DM

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each MINUS_DM value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=MINUS_DM&symbol=MSFT&interval=daily&time_period=10&apikey=demo


PLUS_DM


This API returns the plus directional movement (PLUS_DM) values. See also: Investopedia article


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=PLUS_DM

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each PLUS_DM value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=PLUS_DM&symbol=MSFT&interval=daily&time_period=10&apikey=demo


BBANDS High Usage


This API returns the Bollinger bands (BBANDS) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=BBANDS

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each BBANDS value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Optional: nbdevup

The standard deviation multiplier of the upper band. Positive integers are accepted. By default, nbdevup=2.

❚ Optional: nbdevdn

The standard deviation multiplier of the lower band. Positive integers are accepted. By default, nbdevdn=2.

❚ Optional: matype

Moving average type of the time series. By default, matype=0. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=BBANDS&symbol=MSFT&interval=weekly&time_period=5&series_type=close&nbdevup=3&nbdevdn=3&apikey=demo


MIDPOINT


This API returns the midpoint (MIDPOINT) values. MIDPOINT = (highest value + lowest value)/2.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=MIDPOINT

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each MIDPOINT value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=MIDPOINT&symbol=MSFT&interval=daily&time_period=10&series_type=close&apikey=demo


MIDPRICE


This API returns the midpoint price (MIDPRICE) values. MIDPRICE = (highest high + lowest low)/2.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=MIDPRICE

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each MIDPRICE value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=MIDPRICE&symbol=MSFT&interval=30min&time_period=10&apikey=demo


SAR


This API returns the parabolic SAR (SAR) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=SAR

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Optional: acceleration

The acceleration factor. Positive floats are accepted. By default, acceleration=0.01.

❚ Optional: maximum

The acceleration factor maximum value. Positive floats are accepted. By default, acceleration=0.20.

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=SAR&symbol=MSFT&interval=weekly&acceleration=0.05&maximum=0.25&apikey=demo


TRANGE


This API returns the true range (TRANGE) values. See also: mathematical reference


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=TRANGE

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=TRANGE&symbol=MSFT&interval=daily&apikey=demo


ATR


This API returns the average true range (ATR) values. See also: Investopedia article and mathematical reference


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=ATR

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each ATR value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=ATR&symbol=MSFT&interval=30min&time_period=14&apikey=demo


NATR


This API returns the normalized average true range (NATR) values.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=NATR

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required:time_period

Number of data points used to calculate each NATR value. Positive integers are accepted (e.g., time_period=60, time_period=200)

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=NATR&symbol=MSFT&interval=weekly&time_period=14&apikey=demo



This API returns the Chaikin A/D line (AD) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=AD

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=AD&symbol=MSFT&interval=daily&apikey=demo


ADOSC


This API returns the Chaikin A/D oscillator (ADOSC) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=ADOSC

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Optional: fastperiod

The time period of the fast EMA. Positive integers are accepted. By default, fastperiod=3.

❚ Optional: slowperiod

the time period of the slow EMA. Positive integers are accepted. By default, slowperiod=10.

❚ Required: apikey

Your API key. Claim your free API key here.


Example(click for JSON output)

https://www.alphavantage.co/query?function=ADOSC&symbol=MSFT&interval=30min&fastperiod=5&apikey=demo


OBV High Usage


This API returns the on balance volume (OBV) values. See also: Investopedia article and mathematical reference.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=OBV

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=OBV&symbol=MSFT&interval=weekly&apikey=demo


HT_TRENDLINE


This API returns the Hilbert transform, instantaneous trendline (HT_TRENDLINE) values.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=HT_TRENDLINE

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=HT_TRENDLINE&symbol=MSFT&interval=daily&series_type=close&apikey=demo


HT_SINE


This API returns the Hilbert transform, sine wave (HT_SINE) values.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=HT_SINE

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=HT_SINE&symbol=MSFT&interval=30min&series_type=close&apikey=demo


HT_TRENDMODE


This API returns the Hilbert transform, trend vs cycle mode (HT_TRENDMODE) values.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=HT_TRENDMODE

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=HT_TRENDMODE&symbol=MSFT&interval=weekly&series_type=close&apikey=demo


HT_DCPERIOD


This API returns the Hilbert transform, dominant cycle period (HT_DCPERIOD) values.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=HT_DCPERIOD

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=HT_DCPERIOD&symbol=MSFT&interval=daily&series_type=close&apikey=demo


HT_DCPHASE


This API returns the Hilbert transform, dominant cycle phase (HT_DCPHASE) values.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=HT_DCPHASE

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=HT_DCPHASE&symbol=MSFT&interval=30min&series_type=close&apikey=demo


HT_PHASOR


This API returns the Hilbert transform, phasor components (HT_PHASOR) values.


API Parameters

❚ Required: function

The technical indicator of your choice. In this case, function=HT_PHASOR

❚ Required: symbol

The name of the equity of your choice. For example: symbol=MSFT

❚ Required: interval

Time interval between two consecutive data points in the time series. The following values are supported: 1min, 5min, 15min, 30min, 60min, daily, weekly, monthly

❚ Required: series_type

The desired price type in the time series. Four types are supported: close, open, high, low

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=HT_PHASOR&symbol=MSFT&interval=weekly&series_type=close&apikey=demo


Sector Performances Realtime


SECTOR High Usage


This API returns the realtime and historical sector performances calculated from S&P500 incumbents.


API Parameters

❚ Required: function

The indicator of your choice. In this case, function=SECTOR

❚ Required: apikey

Your API key. Claim your free API key here.


Example (click for JSON output)

https://www.alphavantage.co/query?function=SECTOR&apikey=demo
