Alpha Vantage APIs are grouped into three categories: (1) Time Series Data, (2) Technical Indicators, and (3) Sector Performances. All APIs are realtime: the latest data points are derived from the current trading day. Examples in this documentation are for demo purposes. Claim your free API key today to explore our full API offerings!

## Time Series Data Realtime

Time Series Data provides realtime and historical equity data in 4 different temporal resolutions: (1) intraday, (2) daily, (3) weekly, and (4) monthly. Daily, weekly, and monthly time series contain up to 20 years of historical data. Intraday time series typically span the past 10 to 15 active trading days.

#### TIME_SERIES_INTRADAY High Usage

This API returns intraday time series (timestamp, open, high, low, close, volume) of the equity specified, updated realtime.

**API Parameters**

**❚ Required: function**

The time series of your choice. In this case, `function=TIME_SERIES_INTRADAY`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

Time interval between two consecutive data points in the time series. The following values are supported: `1min`

, `5min`

, `15min`

, `30min`

, `60min`

❚ Optional: `outputsize`

By default, `outputsize=compact`

. Strings `compact`

and `full`

are accepted with the following specifications: `compact`

returns only the latest 100 data points in the intraday time series; `full`

returns the full-length intraday time series. The "compact" option is recommended if you would like to reduce the data size of each API call.

❚ Optional: `datatype`

By default, `datatype=json`

. Strings `json`

and `csv`

are accepted with the following specifications: `json`

returns the intraday time series in JSON format; `csv`

returns the time series as a CSV (comma separated value) file.

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

Downloadable CSV file:
#### TIME_SERIES_DAILY High Usage

This API returns daily time series (date, daily open, daily high, daily low, daily close, daily volume) of the equity specified, covering up to 20 years of historical data.

The most recent data point is the cumulative prices and volume information of the current trading day, updated realtime.

**API Parameters**

**❚ Required: function**

The time series of your choice. In this case, `function=TIME_SERIES_DAILY`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

❚ Optional: `outputsize`

By default, `outputsize=compact`

. Strings `compact`

and `full`

are accepted with the following specifications: `compact`

returns only the latest 100 data points; `full`

returns the full-length time series of up to 20 years of historical data. The "compact" option is recommended if you would like to reduce the data size of each API call.

❚ Optional: `datatype`

By default, `datatype=json`

. Strings `json`

and `csv`

are accepted with the following specifications: `json`

returns the daily time series in JSON format; `csv`

returns the time series as a CSV (comma separated value) file.

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=TIME_SERIES_DAILY&**symbol**=MSFT&**apikey**=demo

`https://www.alphavantage.co/query?`

**function**=TIME_SERIES_DAILY&**symbol**=MSFT&**outputsize**=full&**apikey**=demo

`https://www.alphavantage.co/query?`

**function**=TIME_SERIES_DAILY&**symbol**=MSFT&**apikey**=demo&**datatype**=csv

#### TIME_SERIES_DAILY_ADJUSTED High Usage

This API returns daily time series (date, daily open, daily high, daily low, daily close, **daily split/dividend-adjusted close**, daily volume, **dividend amount**, **split coefficient**) of the equity specified, covering up to 20 years of historical data.

The most recent data point is the cumulative prices and volume information of the current trading day, updated realtime.

**API Parameters**

**❚ Required: function**

The time series of your choice. In this case, `function=TIME_SERIES_DAILY_ADJUSTED`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

❚ Optional: `outputsize`

By default, `outputsize=compact`

. Strings `compact`

and `full`

are accepted with the following specifications: `compact`

returns only the latest 100 data points; `full`

returns the full-length time series of up to 20 years of historical data. The "compact" option is recommended if you would like to reduce the data size of each API call.

❚ Optional: `datatype`

By default, `datatype=json`

. Strings `json`

and `csv`

are accepted with the following specifications: `json`

returns the daily time series in JSON format; `csv`

returns the time series as a CSV (comma separated value) file.

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=TIME_SERIES_DAILY_ADJUSTED&**symbol**=MSFT&**apikey**=demo

#### TIME_SERIES_WEEKLY

This API returns weekly time series (last trading day of each week, weekly open, weekly high, weekly low, weekly close, weekly volume) of the equity specified, covering up to 20 years of historical data.

The latest data point is the cumulative prices and volume information for the week (or partial week) that contains the current trading day, updated realtime.

**API Parameters**

**❚ Required: function**

The time series of your choice. In this case, `function=TIME_SERIES_WEEKLY`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

❚ Optional: `datatype`

By default, `datatype=json`

. Strings `json`

and `csv`

are accepted with the following specifications: `json`

returns the weekly time series in JSON format; `csv`

returns the time series as a CSV (comma separated value) file.

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=TIME_SERIES_WEEKLY&**symbol**=MSFT&**apikey**=demo

`https://www.alphavantage.co/query?`

**function**=TIME_SERIES_WEEKLY&**symbol**=MSFT&**apikey**=demo&**datatype**=csv

#### TIME_SERIES_MONTHLY

This API returns monthly time series (last trading day of each month, monthly open, monthly high, monthly low, monthly close, monthly volume) of the equity specified, covering up to 20 years of historical data.

The latest data point is the cumulative prices and volume information for the month (or partial month) that contains the current trading day, updated realtime.

**API Parameters**

**❚ Required: function**

The time series of your choice. In this case, `function=TIME_SERIES_MONTHLY`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

❚ Optional: `datatype`

By default, `datatype=json`

. Strings `json`

and `csv`

are accepted with the following specifications: `json`

returns the monthly time series in JSON format; `csv`

returns the time series as a CSV (comma separated value) file.

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=TIME_SERIES_MONTHLY&**symbol**=MSFT&**apikey**=demo

`https://www.alphavantage.co/query?`

**function**=TIME_SERIES_MONTHLY&**symbol**=MSFT&**apikey**=demo&**datatype**=csv

## Technical Indicators Realtime

Technical indicator values are updated realtime: the latest data point is derived from the current trading day of a given equity.

#### SMA High Usage

This API returns the simple moving average (SMA) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=SMA`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

Time interval between two consecutive data points in the time series. The following values are supported: `1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each moving average value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

#### EMA High Usage

This API returns the exponential moving average (EMA) values. See also: mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=EMA`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

Time interval between two consecutive data points in the time series. The following values are supported: `1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each moving average value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

#### WMA

This API returns the weighted moving average (WMA) values. See also: mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=WMA`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

Time interval between two consecutive data points in the time series. The following values are supported: `1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each moving average value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

#### DEMA

This API returns the double exponential moving average (DEMA) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=DEMA`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

`time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

#### TEMA

This API returns the triple exponential moving average (TEMA) values. See also: mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=TEMA`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

`time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

#### TRIMA

This API returns the triangular moving average (TRIMA) values. See also: mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=TRIMA`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

`time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

#### KAMA

This API returns the Kaufman adaptive moving average (KAMA) values.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=KAMA`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

`time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

#### MAMA

This API returns the MESA adaptive moving average (MAMA) values.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=MAMA`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

❚ Optional: `fastlimit`

Positive floats are accepted. By default, `fastlimit=0.01`

.

❚ Optional: `slowlimit`

Positive floats are accepted. By default, `slowlimit=0.01`

.

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### T3

This API returns the triple exponential moving average (T3) values. See also: mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=T3`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

`time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

#### MACD High Usage

This API returns the moving average convergence / divergence (MACD) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=MACD`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

❚ Optional: `fastperiod`

Positive integers are accepted. By default, `fastperiod=12`

.

❚ Optional: `slowperiod`

Positive integers are accepted. By default, `slowperiod=26`

.

❚ Optional: `signalperiod`

Positive integers are accepted. By default, `signalperiod=9`

.

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

#### MACDEXT

This API returns the moving average convergence / divergence values with controllable moving average type. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=MACDEXT`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

❚ Optional: `fastperiod`

Positive integers are accepted. By default, `fastperiod=12`

.

❚ Optional: `slowperiod`

Positive integers are accepted. By default, `slowperiod=26`

.

❚ Optional: `signalperiod`

Positive integers are accepted. By default, `signalperiod=9`

.

❚ Optional: `fastmatype`

Moving average type for the faster moving average. By default, `fastmatype=0`

. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

❚ Optional: `slowmatype`

Moving average type for the slower moving average. By default, `slowmatype=0`

. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

❚ Optional: `signalmatype`

Moving average type for the signal moving average. By default, `signalmatype=0`

. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

#### STOCH High Usage

This API returns the stochastic oscillator (STOCH) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=STOCH`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

❚ Optional: `fastkperiod`

The time period of the fastk moving average. Positive integers are accepted. By default, `fastkperiod=5`

.

❚ Optional: `slowkperiod`

The time period of the slowk moving average. Positive integers are accepted. By default, `slowkperiod=3`

.

❚ Optional: `slowdperiod`

The time period of the slowd moving average. Positive integers are accepted. By default, `slowdperiod=3`

.

❚ Optional: `slowkmatype`

Moving average type for the slowk moving average. By default, `slowkmatype=0`

. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

❚ Optional: `slowdmatype`

Moving average type for the slowd moving average. By default, `slowdmatype=0`

. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=STOCH&**symbol**=MSFT&**interval**=daily&**apikey**=demo

#### STOCHF

This API returns the stochastic fast (STOCHF) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=STOCHF`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

❚ Optional: `fastkperiod`

The time period of the fastk moving average. Positive integers are accepted. By default, `fastkperiod=5`

.

❚ Optional: `fastdperiod`

The time period of the fastd moving average. Positive integers are accepted. By default, `fastdperiod=3`

.

❚ Optional: `fastdmatype`

Moving average type for the fastd moving average. By default, `fastdmatype=0`

. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=STOCHF&**symbol**=MSFT&**interval**=daily&**apikey**=demo

#### RSI High Usage

This API returns the relative strength index (RSI) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=RSI`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each RSI value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

#### STOCHRSI

This API returns the stochastic relative strength index (STOCHRSI) values. See also: mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=STOCHRSI`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each STOCHRSI value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

❚ Optional: `fastkperiod`

The time period of the fastk moving average. Positive integers are accepted. By default, `fastkperiod=5`

.

❚ Optional: `fastdperiod`

The time period of the fastd moving average. Positive integers are accepted. By default, `fastdperiod=3`

.

❚ Optional: `fastdmatype`

Moving average type for the fastd moving average. By default, `fastdmatype=0`

. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### WILLR

This API returns the Williams' %R (WILLR) values. See also: mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=WILLR`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each WILLR value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### ADX High Usage

This API returns the average directional movement index (ADX) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=ADX`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each ADX value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=ADX&**symbol**=MSFT&**interval**=15min&**time_period**=10&**apikey**=demo

#### ADXR

This API returns the average directional movement index rating (ADXR) values. See also: mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=ADXR`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each ADXR value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### APO

This API returns the absolute price oscillator (APO) values. See also: mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=APO`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

❚ Optional: `fastperiod`

Positive integers are accepted. By default, `fastperiod=12`

.

❚ Optional: `slowperiod`

Positive integers are accepted. By default, `slowperiod=26`

.

❚ Optional: `matype`

Moving average type. By default, `matype=0`

. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### PPO

This API returns the percentage price oscillator (PPO) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=PPO`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

❚ Optional: `fastperiod`

Positive integers are accepted. By default, `fastperiod=12`

.

❚ Optional: `slowperiod`

Positive integers are accepted. By default, `slowperiod=26`

.

❚ Optional: `matype`

Moving average type. By default, `matype=0`

. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### MOM

This API returns the momentum (MOM) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=MOM`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each MOM value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### BOP

This API returns the balance of power (BOP) values.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=BOP`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=BOP&**symbol**=MSFT&**interval**=15min&**apikey**=demo

#### CCI High Usage

This API returns the commodity channel index (CCI) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=CCI`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each CCI value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=CCI&**symbol**=MSFT&**interval**=daily&**time_period**=10&**apikey**=demo

#### CMO

This API returns the Chande momentum oscillator (CMO) values. See also: mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=CMO`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each CMO value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### ROC

This API returns the rate of change (ROC) values. See also: Investopedia article.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=ROC`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each ROC value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### ROCR

This API returns the rate of change ratio (ROCR) values. See also: Investopedia article.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=ROCR`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each ROCR value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### AROON High Usage

This API returns the Aroon (AROON) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=AROON`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each AROON value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### AROONOSC

This API returns the Aroon oscillator (AROONOSC) values. See also: mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=AROONOSC`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each AROONOSC value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### MFI

This API returns the money flow index (MFI) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=MFI`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each MFI value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### TRIX

This API returns the 1-day rate of change of a triple smooth exponential moving average (TRIX) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=TRIX`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each TRIX value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### ULTOSC

This API returns the ultimate oscillator (ULTOSC) values. See also: mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=ULTOSC`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

❚ Optional: `timeperiod1`

The first time period for the indicator. Positive integers are accepted. By default, `timeperiod1=7`

.

❚ Optional: `timeperiod2`

The second time period for the indicator. Positive integers are accepted. By default, `timeperiod2=14`

.

❚ Optional: `timeperiod3`

The third time period for the indicator. Positive integers are accepted. By default, `timeperiod3=28`

.

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Examples (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=ULTOSC&**symbol**=MSFT&**interval**=daily&**apikey**=demo

#### DX

This API returns the directional movement index (DX) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=DX`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each DX value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=DX&**symbol**=MSFT&**interval**=30min&**time_period**=10&**apikey**=demo

#### MINUS_DI

This API returns the minus directional indicator (MINUS_DI) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=MINUS_DI`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each MINUS_DI value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### PLUS_DI

This API returns the plus directional indicator (PLUS_DI) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=PLUS_DI`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each PLUS_DI value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### MINUS_DM

This API returns the minus directional movement (MINUS_DM) values. See also: Investopedia article

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=MINUS_DM`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each MINUS_DM value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### PLUS_DM

This API returns the plus directional movement (PLUS_DM) values. See also: Investopedia article

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=PLUS_DM`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each PLUS_DM value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### BBANDS High Usage

This API returns the Bollinger bands (BBANDS) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=BBANDS`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each BBANDS value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

❚ Optional: `nbdevup`

The standard deviation multiplier of the upper band. Positive integers are accepted. By default, `nbdevup=2`

.

❚ Optional: `nbdevdn`

The standard deviation multiplier of the lower band. Positive integers are accepted. By default, `nbdevdn=2`

.

❚ Optional: `matype`

Moving average type of the time series. By default, `matype=0`

. Integers 0 - 8 are accepted with the following mappings. 0 = Simple Moving Average (SMA), 1 = Exponential Moving Average (EMA), 2 = Weighted Moving Average (WMA), 3 = Double Exponential Moving Average (DEMA), 4 = Triple Exponential Moving Average (TEMA), 5 = Triangular Moving Average (TRIMA), 6 = T3 Moving Average, 7 = Kaufman Adaptive Moving Average (KAMA), 8 = MESA Adaptive Moving Average (MAMA).

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### MIDPOINT

This API returns the midpoint (MIDPOINT) values. MIDPOINT = (highest value + lowest value)/2.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=MIDPOINT`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each MIDPOINT value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### MIDPRICE

This API returns the midpoint price (MIDPRICE) values. MIDPRICE = (highest high + lowest low)/2.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=MIDPRICE`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each MIDPRICE value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### SAR

This API returns the parabolic SAR (SAR) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=SAR`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

❚ Optional: `acceleration`

The acceleration factor. Positive floats are accepted. By default, `acceleration=0.01`

.

❚ Optional: `maximum`

The acceleration factor maximum value. Positive floats are accepted. By default, `acceleration=0.20`

.

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### TRANGE

This API returns the true range (TRANGE) values. See also: mathematical reference

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=TRANGE`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=TRANGE&**symbol**=MSFT&**interval**=daily&**apikey**=demo

#### ATR

This API returns the average true range (ATR) values. See also: Investopedia article and mathematical reference

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=ATR`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each ATR value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=ATR&**symbol**=MSFT&**interval**=30min&**time_period**=14&**apikey**=demo

#### NATR

This API returns the normalized average true range (NATR) values.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=NATR`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: time_period**

Number of data points used to calculate each NATR value. Positive integers are accepted (e.g., `time_period=60`

, `time_period=200`

)

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### AD High Usage

This API returns the Chaikin A/D line (AD) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=AD`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=AD&**symbol**=MSFT&**interval**=daily&**apikey**=demo

#### ADOSC

This API returns the Chaikin A/D oscillator (ADOSC) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=ADOSC`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

❚ Optional: `fastperiod`

The time period of the fast EMA. Positive integers are accepted. By default, `fastperiod=3`

.

❚ Optional: `slowperiod`

the time period of the slow EMA. Positive integers are accepted. By default, `slowperiod=10`

.

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example(click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=ADOSC&**symbol**=MSFT&**interval**=30min&**fastperiod**=5&**apikey**=demo

#### OBV High Usage

This API returns the on balance volume (OBV) values. See also: Investopedia article and mathematical reference.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=OBV`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=OBV&**symbol**=MSFT&**interval**=weekly&**apikey**=demo

#### HT_TRENDLINE

This API returns the Hilbert transform, instantaneous trendline (HT_TRENDLINE) values.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=HT_TRENDLINE`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### HT_SINE

This API returns the Hilbert transform, sine wave (HT_SINE) values.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=HT_SINE`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### HT_TRENDMODE

This API returns the Hilbert transform, trend vs cycle mode (HT_TRENDMODE) values.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=HT_TRENDMODE`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### HT_DCPERIOD

This API returns the Hilbert transform, dominant cycle period (HT_DCPERIOD) values.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=HT_DCPERIOD`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### HT_DCPHASE

This API returns the Hilbert transform, dominant cycle phase (HT_DCPHASE) values.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=HT_DCPHASE`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

#### HT_PHASOR

This API returns the Hilbert transform, phasor components (HT_PHASOR) values.

**API Parameters**

**❚ Required: function**

The technical indicator of your choice. In this case, `function=HT_PHASOR`

**❚ Required: symbol**

The name of the equity of your choice. For example: `symbol=MSFT`

**❚ Required: interval**

`1min`

, `5min`

, `15min`

, `30min`

, `60min`

, `daily`

, `weekly`

, `monthly`

**❚ Required: series_type**

The desired price type in the time series. Four types are supported: `close`

, `open`

, `high`

, `low`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

## Sector Performances Realtime

#### SECTOR High Usage

This API returns the realtime and historical sector performances calculated from S&P500 incumbents.

**API Parameters**

**❚ Required: function**

The indicator of your choice. In this case, `function=SECTOR`

**❚ Required: apikey**

Your API key. Claim your free API key here.

**Example (click for JSON output)**

`https://www.alphavantage.co/query?`

**function**=SECTOR&**apikey**=demo
